Steel Auto Bearing

Maisheng’s steel auto bearing is produced referencing mainstream OE installation dimensions to fit various passenger and commercial vehicles smoothly without on-site trimming. We arrange flexible order schemes to satisfy varied demands, ranging from trial small lots for independent repair garages to full-container bulk shipments for regional aftermarket distributors. Every finished bearing passes real-load assembly verification before shipment to lower fitting failure risks and help buyers stabilize their local spare-parts sales business.

Product Specifications

Our steel auto bearing provides stable rotational support for vehicle chassis and transmission systems, effectively reducing running friction and prolonging the service life of supporting automotive components.

More Steel Auto Bearing

Ring Forging and Heat Treatment Control

The inner and outer rings start as hot forged blanks from vacuum degassed bearing steel, typically a high carbon chromium grade equivalent to GCr15 or 100Cr6. After forging, the rings undergo a spheroidizing annealing cycle to soften the structure and prepare it for machining. A subsequent through hardening treatment in a controlled atmosphere furnace brings the raceway hardness to a range between 58 and 62 HRC, while the core retains sufficient toughness to resist crack formation under impact loads. Every heat treat batch is verified with a microhardness traverse and a metallographic sample to confirm that retained austenite and carbide distribution stay within the specification limits required for automotive bearing life.

Raceway Finishing and Running Accuracy

Following hardening, the ring raceways are ground and then superfinished on a through feed or plunge machine to achieve a surface finish below Ra 0.15 micrometres. This low roughness value directly reduces friction torque and keeps the bearing quiet across the full speed range of a passenger car or light commercial vehicle. The rolling elements are matched into sets with a diameter variation not exceeding two micrometres, and the cage pockets are stamped or machined to hold each ball at an equal pitch, preventing irregular loading. After assembly, the bearing radial internal clearance is set to a CN or C3 class according to the customer's application requirements, and the outer ring is marked with the batch code for full traceability.

Vibration and Endurance Validation

A 100 percent vibration test is carried out on automated bearing testers that record the velocity signal in three frequency bands, flagging any unit that shows an abnormal signature. A random sample from each production shift is then loaded onto a life test rig and run under combined radial and axial loads for hundreds of hours, while temperature and torque are continuously logged. This endurance data is used to confirm the calculated L10 fatigue life and to validate process consistency over time. Additional salt mist exposure trials are performed on sealed versions to ensure that the rubber lip and stainless steel slinger offer sufficient corrosion protection for chassis locations exposed to road spray.

Manufacturing Scale and Supply Flexibility

The bearing production line is part of a larger manufacturing facility based in Ningbo, which has been active in the automotive component sector since 1999 and covers over 30,000 square metres. This site integrates turning, grinding, heat treatment and assembly under one roof, with a separate metrology laboratory that maintains master gauges and reference standards calibrated to national and international references. The quality management system is registered to IATF 16949 and ISO 9001, and all production records are retained for a minimum of fifteen years. Small trial batches and full container shipments are managed on the same production schedule, with dimensional and material certificates provided for every consignment. Customers who require their own brand on the bearing and packaging can receive tailored marking and box design with a standard lead time confirmed at the order stage.

FAQ

1.How to confirm whether a steel auto bearing matches the target vehicle assembly?

A: First confirm the OEM part number of the original vehicle bearing; second verify three core parameters: inner bore diameter, outer ring outer diameter, overall width; additionally check rolling body type, sealing structure, standard bearing clearance and maximum rated load. Each vehicle axle, engine and gearbox model corresponds to exclusive bearing size, mismatched size will cause shaft jamming, overheating and premature damage.

2.Can steel auto bearings be used on new energy electric vehicles?

A: Fully applicable. We provide GCr15 high-precision low-noise steel bearings specially developed for new energy vehicle electric drive axles and electric water pumps, with optimized small clearance design to adapt high-speed silent operation requirements of electric drive systems, and the double-layer sealing structure can resist electric vehicle cooling liquid splashing corrosion.
